Original white WJD1301R square PTC heater with rectangular black grille and control panel on the base. — WJD1301R · Original supplier image

// Model Specifications

WJD1301R Square-Body PTC Heater Specifications

Review this model's specifications and prepare an inquiry with Wanjiada.

A square-body PTC unit differs from WJD1302R. Separate fields record fan-only operation, heating, product size and inner-box dimensions.

900 / 1,300 W
Heating power: 220 V / 50 Hz
Listed supply: PTC
Heating mode

Ask about this model Technical specifications

Model selection checklist

Start with electrical compatibility and the intended heating requirement.

Supply and power settings: Review voltage and wattage. Confirm frequency and plug configuration for the destination market.
Instructions and safety evidence: Ask for exact-model operating instructions and required compliance documents; no generic protective-function claim is assumed.

// Model Parameters

Technical specifications

WJD1301R · Confirmed technical parameters
Model	WJD1301R
Heating mode	PTC
Listed voltage / frequency	220 V / 50 Hz
Fan-only power	8 W
Heating power settings	900 / 1,300 W
Product dimensions (L × W × H)	205 × 180 × 285 mm
Single-item inner box dimensions	210 × 185 × 290 mm
Net weight (single item)	1.5 kg
Gross weight (single-item inner box)	1.7 kg

Imperial measurements are approximate conversions. Packaging and final configuration are confirmed with the order.

Original WJD1301R alternate pink-housing front-angle view, not a rear view or safety test. — Original alternate colour view — colours and supplied controls require order confirmation.

Applications and compatibility

Compare dimensions with the intended space and request placement/clearance instructions. Heating wattage does not establish room coverage or temperature rise.

Confirm 220 V / 50 Hz, plug and cable. Fan-only power and heating settings are not three fan speeds. WJD1302R remains a separate model.

Documents and ordering

No exact-model WJD1301R certificate or approved public datasheet is attached. Request configuration-specific safety and destination-market records.

Confirm colours, controls, supplied parts, MOQ, sample availability and charges, packing, production lead time and delivery schedule. Timer, swing and protective functions require separate verification.

Discuss these specifications

Before you place an order

Discuss these requirements

Model and market documents: Request exact-model documents for your destination.
Minimum order and samples: Confirm MOQ, sample availability and charges.
Packaging and delivery: Agree packing, quantity and schedule in the quote.
