Original WJD801R red upright cylindrical PTC heater with oval black front grille.
WJD801R · Original supplier image

// Model Specifications

WJD801R Compact PTC Heater Specifications

Review this model's specifications and prepare an inquiry with Wanjiada.

A compact cylindrical PTC body identifies WJD801R. Fan-only and heating fields are separate, as are product size, inner-box dimensions and labelled weights.

800 W
Heating power
220 V / 50 Hz
Listed supply
PTC
Heating mode

Model selection checklist

Start with electrical compatibility and the intended heating requirement.

Supply and power settings
Review voltage and wattage. Confirm frequency and plug configuration for the destination market.
Instructions and safety evidence
Ask for exact-model operating instructions and required compliance documents; no generic protective-function claim is assumed.

// Model Parameters

Technical specifications

WJD801R · Confirmed technical parameters
ModelWJD801R
Heating modePTC
Listed voltage / frequency220 V / 50 Hz
Fan-only power6 W
Heating power800 W
Product dimensions (L × W × H)130 × 130 × 235 mm
Single-item inner box dimensions140 × 140 × 250 mm
Net weight (single item)0.85 kg
Gross weight (single-item inner box)0.97 kg

Imperial measurements are approximate conversions. Packaging and final configuration are confirmed with the order.

Original WJD801R pink-housing alternate front view; not a rear view or measured heating test.
Original alternate colour view — availability and supplied configuration require confirmation.

Applications and compatibility

Compare footprint and height with the intended space and request placement/clearance instructions. Power ratings do not guarantee heated-room area or heating time.

Confirm 220 V / 50 Hz, plug and cable. Fan-only 6 W and heating 800 W are separate operating ratings, not two fan speeds.

Documents and ordering

Confirm colours, controls, supplied parts, MOQ, sample availability and charges, packing, production lead time and delivery schedule. Swing, cooling-delay and protective functions require separate verification.

Discuss these specifications

Before you place an order

Discuss these requirements
Model and market documents
Request exact-model documents for your destination.
Minimum order and samples
Confirm MOQ, sample availability and charges.
Packaging and delivery
Agree packing, quantity and schedule in the quote.
