Original WJD8000F-1Z front three-quarter view with a white housing and dark tank — WJD8000F-1Z · Original supplier image

// Model Specifications

WJD8000F-1Z Air Cooler Specifications

Review this model's specifications and prepare an inquiry with Wanjiada.

The WJD8000F-1Z record pairs a product view with an application illustration. Supply requirements and model-specific documents need confirmation.

8,000 m³/h
High-speed airflow: 80 L
Water tank: 200 W
Rated power

Ask about this model Technical specifications

Cooler selection checklist

Use the model figures alongside the requirements of the intended setting.

Setting and ventilation: Describe the space and local climate. Ask our team to assess suitability; no cooling-area figure is assumed.
Power and destination: Identify the available electrical supply and destination market so power accessories and relevant documents can be checked.

// Model Parameters

Technical specifications

WJD8000F-1Z · Confirmed technical parameters
Model	WJD8000F-1Z
Rated power	200 W
Fan speeds	3 settings
Airflow — high	8,000 m³/h
Airflow — medium	6,000 m³/h
Airflow — low	3,500 m³/h
Water tank capacity	80 L
Product dimensions (L × W × H)	680 × 410 × 1,250 mm
Net weight	18 kg
Gross weight	21 kg
Carton dimensions (inverted tank)	695 × 460 × 980 mm

Imperial measurements are approximate conversions. Packaging and final configuration are confirmed with the order.

WJD8000F-1Z placed over a factory scene with illustrated airflow — Original supplier illustration, not a completed customer project or a performance test.

Applications and compatibility

The factory scene is a supplier illustration, not a customer installation or industrial rating. Share the intended setting, humidity, ventilation and space dimensions for suitability review.

Voltage and frequency are not listed. Confirm supply and plug before ordering. Assembled and packed dimensions refer to different configurations: the tank is inverted for packing.

Documents and ordering

Confirm minimum order, samples, accessory list, loading quantities, packing and lead time for your requested configuration and destination.

Discuss these specifications

Before you place an order

Discuss these requirements

Model and market documents: Request exact-model documents for your destination.
Minimum order and samples: Confirm MOQ, sample availability and charges.
Packaging and delivery: Agree packing, quantity and schedule in the quote.

// Model & Project Inquiries

Tell us which model you need

Ask about model selection, an order, OEM/ODM customization or a separate plastic molding project.

Air coolers on Wanjiada’s factory assembly line — Original Wanjiada factory photograph

Files for your inquiry

Send supporting files separately to wanjiada@gdboost.com. Include the same model or project reference as your form submission.

Email Wanjiada directly

Model-selection information: A photograph or layout of the intended space, its dimensions and the available electrical supply can help explain the requirement.
Order or customization references: Email any model list, packaging artwork or drawing relevant to your inquiry, using the same name and project reference.
